The BMP561EVM is an evaluation module (EVM) for testing the BMP561 single-cell lithium battery fuel gauge IC. It includes the BMP561 chip and an external sense resistor for accurate battery capacity measurement. To use it, connect a battery cell (or power supply) and an I2C (communication box). A system load or charger can also be connected to test charge and discharge performance.
Complete fuel gauge evaluation solution
Pre-installed circuit modules for fast setup
Supports data logging and system parameter configuration via PC
|
|
|
Format | Size |
|
|---|---|---|---|---|---|
| BMP561 EVM User Manual | Development Board Manual | V1.0 | 1.06 MB | May 19, 2025 | |
| BMP561 EVM Schematic Diagram | Development Board Schematic | V1.0 | 80.84 KB | May 19, 2025 |
